10 years focus on LED outdoor lighting power supply R & D and production
7 Years
| Ask Lasest Price | |
| Brand Name : | Zhongfu |
| Model Number : | ZF-HBG-100-36H |
| Certification : | CE FCC ROHS SAA TUV |
| Supply Ability : | 10000 Piece/Pieces per Month 100w led driver 36v |
| Price : | Negotiable |
1 Use Best quality material,such as Rubycon and NCC
capacitor,Toshiba MOS,Infenion IC.
2. high PFC,high efficiency,low Ripple
3. universal AC input 90-277V
4. Could be dimming function three-in-one online dimming,current
can be adjustable
5. IP67,can use indoor or outdoor
6. 5 years warranty,best service for you.
Model No. | ZF-HLB-100-36 | ZF-HLB-100-48 | ZF-HLB-100-60 | ZF-HLB-100-72 |
input voltage | 90-277V | 90-277V | 90-277V | 90-277V |
output voltage | 27～36Vdc | 36～48Vdc | 48～60Vdc | 60～72Vdc |
current | 3.5～2.8A | 2.8～2.0A | 2.0～1.7A | 2.0～1.4A |
PFC | PF>0.99 at 100Vac＆full load; PF>0.97 at 230Vac＆load | |||
efficiency | 88% | 89% | 90% | 91% |
ripple current | 400mA Max | 300mA Max | 200mA Max | 200mA Max |
permissible error | +/-3% | |||
Surge current | 277Vac input the Max 80A | |||
MTBF | 200Khours@ 25℃ | |||
Working temperature | -40---+60℃ | |||
Humidity | 0-95%RH | |||
safty standards | EN 61347-1:2008+A1:2011+A2:2013 , EN 61347-2-13:2006 , EN
62493:2010 | |||
Leak current | 0.75mA max @ 277Vac 50Hz input | |||
Surge | 4KV | |||
size | 180*70*40mm | |||
We use Glass fiber double panel,Good conduction, good conductivity.
high temperature resistance,moistureproof.
NCC capacitor,famous brand from Japan,the quality is as same as the Rubycon.The lifespan is about 10000 hours when the temperature is reach to 105 degree,each reduce 10 degree,the lifespan will be increase 10000 hours,long lifespan.
Adopted with 100% copper wires,isolation,good voltage regulation performance,active PFC.
To protect the circuit from the transient voltage of the power supply system.When high pressure comes, the resistance of the pressure sensitive resistor decreases and the current is diverted to prevent excessive instantaneous voltage damage or interference.Thus, sensitive electronic components are protected
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
A: Low MOQ, 1pc for sample checking is available
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the samples and places deposit for formal
order.
Fourthly We arrange the production.
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A: Yes, we offer 3-5 years warranty to our products.
A: Firstly, Our products are produced in strict quality control
system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with
new order for small quantity. For
defective batch products, we will repair them and resend them to
you or we can discuss the solution i
ncluding re-call according to real situation.
|
|
