Brand Name : | Turefull |
Model Number : | ZF-HLB-60W-XL |
Certification : | CE/ROHS/FCC/TUV/SAA |
Supply Ability : | 10000 Piece/Pieces per Month Single output waterproof 60w 36v constant current led drivers |
Price : | Negotiable |
Payment Terms : | T/T |
Delivery Time : | 5-10 work days |
Features
1.Universal input voltage(90-277V)
2.Output current and voltage can be customized
3.Support(1-10V/Pwm/resistance three-in-one online dimming
4.high PFC,low ripple
5.high efficiency(up to 93%)
6.protection design:OVP/OCP/SCP/OTP)
7.5 years warranty
Parameters
Model No | ZF-HLB-60-36 | ZF-HLB-70-36 | ZF-HLB-80-36 | ZF-HLB-100-36 |
output voltage | 28-38V | 28-38V | 28-38V | 28-38V |
rated current | 1.8A | 2.1A | 2.4A | 3A |
rated power | 60W | 70W | 80W | 100W |
ripple | <5% | |||
current accuracy | +/-3% | |||
input voltage | 90-277V | |||
fruquency | 47-63HZ | |||
warranty | 5 years warranty | |||
size | 130*44*32mm | 128*70*40mm | 138*70*40mm | 158*70*40mm |
![]() |
