| Brand Name : | Turefull |
| Model Number : | ZF-CV-12150 |
| Certification : | CE ROHS |
| Supply Ability : | 5000 Piece/Pieces per Month |
| Price : | Negotiable |
1. AC input range ,constant DC output
2. Protections: Short circuit / Overload / Over voltage / Over
temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
Model | ZF-CV-12150 | ZF-CV-24150 | ZF-CV-36150 | ZF-CV-48150 |
Dc output voltage | 12V | 24V | 36V | 48V |
Rated output current | 12.5A | 6.25A | 4.16A | 3.125A |
Output current rage | 0~12.5A | 0~6.25A | 0~4.16A | 0~3A |
Rated Power | 150W | 150W | 150W | 150W |
Wave and noise | 100mVp-p | 150mVp-p | 150mVp-p | 150mVp-p |
Efficiency | 81% | 83% | 83% | 84% |
AC input voltage range | AC85~264V 47~63Hz;254~373VDC | |||
Input current | 1.6A/115V 0.85A/230V | |||
AC INnrush current | Cold-start 30A/230V | |||
Overload proctection | 105%~150% Potection type: Hiccp mode, recobers automatically after condition recoverd | |||
Protection | Potection type :Shut down o/p voltage,re-power on to recover | |||
Setup rise time | 500ms,20ms/230VAC 500ms,20ms/115VAC at full lod | |||
Hold up time | 24ms/230VAC ,24ms/115VAC at full lod | |||
Withstand voltage | I/P-O/P:1.5KVAC,I/P-FG:1.5KVAC,O/P-FG: 0.5KVAC | |||
Isolation resistance | I/P-O/P,I/P-FG,O/P-FG:100M Ohms/ 500VDC /25°C/70%RH | |||
Working temperature | -10°C~+50°C | |||
Overall dimension | 190*48*38mm | |||
EMC standards | Meet EN55022,EN61000-3-2,EN61000-3-3,EN55024 GB9254 Class B | |||
Weight | 0.78Kgs | |||
Our company was founded in 2009, is a professional waterproof lighting power supply, high-tech enterprise integrating R & D, manufacturing, trade, services and other functions in one,providing types of constant current LED driver is stable and reliable for all types of lighting project;
The company has nearly 3000 square meters of modern workshop, the existing staff of 100 people,the company passed the ISO9001 quality system certification, the product through the CCC,TUV, SGS, SAA, CE, ROHS etc.
|
|
