| Brand Name : | turefull |
| Model Number : | ZF-HTG-80XL |
| Supply Ability : | 10000 Piece/Pieces per Month 0-10V dimmable LED driver |
| Price : | Negotiable |
Constant current LED driver 0-10 V dimmable LED driver
Features
Specification
| Model No. | ZF-HTG-70H-48 | ZF-HTG-70H-48 | ZF-HTG-70H-48 | ZF-HTG-70H-48 | ZF-HTG-70H-48 | Customized | |
| output | No load voltage | 49VDC | 66VDC | 89VDC | 101VDC | 131VDC | undetermined |
| output current | 1.4A | 1.1A | 0.81A | 0.71A | 0.55A | undetermined | |
| Fan-output voltage | 12VDC | ||||||
| fan-output current | 0.3A | ||||||
| PWM control signal voltage | 3-12V DC | ||||||
| PWM frequency | 2-15KHZ | ||||||
| dimming range | 0-100% | ||||||
| output power | 75W | 75W | 75W | 75W | 75W | 75W | |
| Ripple and noise | 3000mVAC | 3000mVAC | 23000mVAC | 2000mVAC | 2000mVAC | 3000mVAC | |
| output voltage range | 28-48VDC | 35-65VDC | 50-88VDC | 60-100VDC | 80-130VDC | customized | |
| Current Error | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% | |
| Efficiency | 88% | 88% | 89% | 89% | 89% | ||
| Line regulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±1% | |
| load ragulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±1% | |
| input | start time | 500mS,1000ns(full load)230VAC/115VAC | |||||
| Hold time | 10mS full load 230VAC/115VAC | ||||||
| Frquency range | 47-63HZ | ||||||
| PFC | PF>0.94 230V AC full load | ||||||
| input voltage | 100-300VAC | ||||||
| AC current | 0.9A/115VAC,0.5A/230VAC,0.4A/277VAC | ||||||
| surge current | cold start <50A/230VAc | ||||||
| leakage current | <0.75MA/277VAC | ||||||
| protection | over current protection | 95-105% protect mode:constant limitation | |||||
| over-voltage protection | protect mode:constant voltage limitation | ||||||
| over-temp. | 145°C ± 10°C,start | ||||||
| Environmental | Work-temp. | --40--+55°C | |||||
| Work-humidity | 20-95%RH,no condensation | ||||||
| Storage temp.humidity | --40--+80°C, 10-95%RH, | ||||||
| Max temp.rise | +55°C No wind open environment | ||||||
| Vibration Resistance | 10-500HZ,5G 12 minute/cycle,X,Y,ZAxis each 72 minutes | ||||||
| withstand voltage | I/P-O/P:3.75KVAC | ||||||
| Insulation Resistance | I/P-O/P:100M Ohms/500VDC/25°C/70%RH | ||||||
| Safety standard | EN61347-1:2008+A1:2011+A2:2013,EN61347-2-13:2006,EN62493:2010 | ||||||
| Others | MTBF | ≥150Khrs MIL-HDBK-218F(25°C) | |||||
| size | L153*W53*H37.5mm | ||||||
| packing | Use box | ||||||
Dimensions
Product show
Company information
Shenzhen ZhongFu Photoelectric Technology Co. Ltd located in Shenzhen China since 2009,is a High-tech Enterprise which is engaged in designing,manufacturing and selling all kinds of indoor&outdoor LED Lighting drivers.Our company have experienced R&D team and advance R&D test equipment,we established independent quality management system,got ISO9001 quality management system certification,achieved “National New High-tech enterprise”,Chinese enterprises credit AAA grade honorary title.
We mainly concentrate on constant current street/flood /tunnel light driver,high bay/grow light driver,DC/DC converters,etc.,can offer OEM / ODM service. Our products have been passed CE ROHS TUV,SAA CCC certification,the product sells all around Europe,Northern America, Southeast Asia.
Certification
Our exhibition
Models for choice
Packing and Shipping
|
|
